AirSuite™ Sense LTE
Front of an AirSuite sensorThe box of an AirSuite sensorAn AirSuite sensor being mounted on a wall
Stock available now

Overview

AirSuite™ Sense sensors are intelligent devices that we originally designed to monitor the conditions in classrooms and early-childhood education (ECE) centres, following a successful trial programme with the New Zealand Ministry of Education. Since then, we’ve added more features to make them perfect for deploying in a number of other situations too, including in residential, aged care, and commercial environments.

Each device is packed with a powerful array of sensors that monitor all important environmental factors including thermal comfort, ventilation, lighting, and acoustics. AirSuite™ Sense sensors have a wireless connection to the Internet and provide a live feed of sensor data securely into the AirSuite Cloud.

For most customers, we recommend AirSuite™ Sense LTE, which provides the most flexibility around how and where you can deploy your sensors, and eliminates the hassle and security challenges of managing your own Wi-Fi networks.

Powered by the Spark IoT network and with up to 3 years battery life, AirSuite™ Sense LTE devices are particularly suitable even if you don’t have full control of the power or network connectivity at the property where they will be installed. Alternatively, they can be mains-powered from a standard USB power supply or from a permanent (in-wall) installation kit.

AirSuite™ Sense Wi-Fi is also available for customers requiring extremely high resolution data, such as for scientific modelling and reporting.

AirSuite™ Sense

SSCM860 (LTE)

Powered by Spark IoT

Connectivity

Features

  • CO2
  • Temperature
  • Humidity
  • Acoustics
  • Lighting
  • Air pressure
  • Volatile organic compounds
    Available when mains-powered, or discuss with us to enable in battery-powered mode

Optional add-ons

Available when mains-powered (battery not included)
  • Particulate Matter
    Measures PM1, PM2.5, PM4, and PM10
  • Carbon Monoxide New
  • Biochemical sensor array Available soon
    Measures CO, SO₂, HCHO, and NOx

One add-on sensor can be added to each Sense LTE device. The add-on replaces the included battery, so devices containing add-ons must be mains-powered.

Installation options

  • Standard wall-mount kit
  • Tamper-proof wall-mount kit

* Battery life depends on cellular network conditions in your area, including signal strength (how close you are to the nearest cell tower, and obstruction from hills, trees, buildings and walls) and interference/congestion (other devices using the network).

An AirSuite Sense LTE device with a moderate signal strength is likely to achieve 2-3 years of battery life, as tested in our lab in Hamilton, New Zealand (RSRP -100dBm). We recommend connecting devices with consistently poor signal strength (less than -115dBm) to mains power.

An AirSuite Sense device being mounted to the wall

AirSuite™ + Data Nerds = ❤️

A chart showing sound measurements taken across one hourA chart showing sound measurements taken across one hour
High resolution sound data collected by an AirSuite sensor over a one hour period.

All AirSuite™ sensors are built to capture data at the highest possible resolution, ideal for scientific analysis, without sacrificing quality or battery life. The data can also be exported in summarised forms, so you can choose the most appropriate resolution for your analysis.

Measurement frequency

The interval between when each sensor measurement is taken. These measurements are available in real-time in the AirSuite Monitor App.

  • LTE: Once per minute
  • Wi-Fi: Once per 10 seconds

Reporting frequency

The frequency at which devices send measurements to the Cloud (time between new data appearing in the AirSuite Monitor Portal).

  • LTE: Once per 15 minutes (configurable batch reporting)
    • Battery life optimised with intelligent dynamic reporting
  • Wi-Fi: Same as measurement frequency (immediate reporting)

Maximum Security

All AirSuite™ devices are designed to enterprise security standards, capable of receiving over-the-air (OTA) updates, and guaranteed to receive routine security and maintenance patches for at least 5 years. This allows us to remotely manage your devices even after they’ve been deployed throughout the country, and is made possible through our use of Spark’s brand new, high-bandwidth LTE Cat-M1 network for IoT devices.

  • Automatic OTA feature enhancements for 3+ years
  • Automatic OTA security updates guaranteed for 5+ years

AirSuite regularly undertakes security audits of our platform through an independent third party. Our most recent audit was completed by CyberCX in March, 2023.

Ready to connect

One part of your complete air quality intelligence solution

Talk to the AirSuite™ Consulting team to define your objectives and build a system to achieve your goals
Learn more
Learn more about how AirSuite™ Monitor software turns sensor data into actionable insights
Learn more

Customer stories

The New Zealand Ministry of Education logo

Shaping the Ministry of Education’s building management strategy

We’ve been working with the New Zealand Ministry of Education since 2017 to help them better understand the quality of the learning environments in Aotearoa and the impacts of environmental conditions.

AirSuite™ data from thousands of sensors, reporting tools and insights are helping to reshape the way investment decisions are made and how building assets are managed. The Ministry of Education’s wealth of data and understanding are now driving the creation of environments that better support learning and wellbeing across the country.

Students looking into microscopes in a science class

Let’s talk about how AirSuite™ can deliver real indoor outcomes for your organisation today
